What is TSM and PSM of a relay and how to calculate

Relay Time Setting Multiplier and Plug Setting Multiplier calculation



Relay time setting multiplier (TSM) and plug setting multiplier (PSM) are the two key parameters required to calculate the operating time of the relay. Having knowledge of these two is very important in order to understand the relay operation.
Remember These two terms are related with the IDMT type relay, they are irrelevant for the definite type relays.
So let's know about the relay TSM and PSM
What is Time Setting Multiplier (TSM) : TSM or Time Setting Multiplier of relay is defined as the ratio of actual operating time to the ideal operating time (operating time obtained from PSM vs Time graph).
Some time it is also written as Time multiplier or TMS.

What is Plug Setting Multiplier (PSM)
PSM or Plug Setting Multiplier is defined as the ratio of fault current from CT secondary to the pickup current of the relay.

Remember : pickup current is the minimum current required to start the relay operation.

For exampl…
